Swing away pulley block designed to be a fast and efficient option for increasing line pull. This block is for use with wire winch ropes.

• 100 mm Sheave diameter.
• Wire rope diameter 10-12mm
• Electro galvanised finish.
• Recommended WLL for lifting 3400 kg.
• Recommended WLL for hauling 9100 kg.

A Snatch Block is a great aid to winching operations:

• By increasing load pulling capacity
• By facilitating a change of direction of the pull if required
• By improving life expectancy of the winch and rope through  reducing the strain applied on them

Using one snatch block allows you to 'double the rope', which in turn doubles the lifting/pulling capacity of the snatch block and winch arrangement. If additional snatch blocks can be used in conjunction with the winch, it will further increase load pulling capacity.

All of our snatch blocks are supplied with certification.
